Product Details:
Place of Origin: China
Brand Name: HEMEI
Model Number: 50*14mm
Payment & Shipping Terms:
Minimum Order Quantity: 100
Price: negotiable
Packaging Details: Standard Carton
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000PCS/MONTH

Electrical Nodes Wireless Temperature Sensors Controller 433MHz

Description
Measurement Range: -25~+125℃ Accuracy: ±0.5℃
Temperature Probe: Digital Temperature Sensor Temperature Sampling Frequency: 10 Seconds By Default
Sending Frequency: Send Data Once Within 10-15S When The Temperature Changes Above 2℃, Send Data In Real Time Communication Method: Lora
Frequency: 433MHz-470MHz Transmission Distance: <300m
Working Power Supply Induction Power: ≤5A Start Work Installation Type: Bundled
High Light:

433MHz Wireless Temperature Sensors

,

Electrical Nodes Wireless Temperature Sensors

,

433MHz Wireless Temperature Controller

Wireless Temperature Sensor For Online Temperature Monitoring Of Electrical Nodes In Important Circui

Not only maintains the advantages of the original wireless temperature measurement, but also greatly improves the positioning of the temperature measurement and reduces the temperature measurement cycle. Moreover, it learns the lesson of low system stability of the optical fiber temperature measurement series method, and solves the problem of anti-pollution flashover. Moreover, due to the use of wireless signal transmission, there is no electromagnetic interference and regular maintenance problems, and it can operate reliably without maintenance for a long time, which is fully compatible with unmanned substations.

Jean:
1. The safety of temperature measurement system products: this series of products adopt Zigbee wireless method to realize temperature online monitoring. The temperature sensor is directly installed on high-voltage electrical equipment, and the temperature data sampled by the temperature sensor is transmitted through radio waves, thus realizing Complete isolation of high voltage. Ensure the absolute safety of product application.
2. Eliminate safety accidents caused by high temperature of high-voltage equipment, and ensure the safe operation of electrical equipment systems and the safe production of enterprises.
Reliable
1. Our company's series of temperature measurement products have been used in various industries and have been operating safely for more than 6 years.
2. This series of products have passed various tests by authoritative testing institutions.
3. Because the system realizes the real-time temperature monitoring function, the heating fault of the equipment can be found in time. And through the statistics and analysis of historical data, timely early warning of equipment problems can be made to ensure the reliable operation of the equipment.


Simple and flexible
1. The product is easy to install and use. There are various types of temperature sensors suitable for different occasions. The installation of the sensor will not affect or reduce the safety performance of the equipment.
2. Our company has developed products for various applications and a variety of networking solutions to facilitate the needs of different customers.
3. According to the specific needs of customers, the company can design corresponding programs specifically and specifically.
Effectiveness


1. It solves the labor intensity of regular on-site inspections of the staff under the traditional method and the high cost caused by the increase of staff.
problem.
2. It solves the problem of inaccurate temperature measurement in traditional temperature measurement methods and large interference factors caused by man-made and environmental factors.
3. Eliminate the occurrence of equipment failure due to equipment heating, ensure the safe, reliable and continuous operation of the equipment, and improve
Improve the economic benefits of the enterprise.
4. The system can detect and predict equipment failures in time, eliminate equipment failures in advance, and reduce equipment damage.
Bad, reducing the maintenance cost of the enterprise.


Power industry applications
Electrical equipment in operation usually works at high voltage and high current. Certain defects in the equipment will cause abnormal temperature rise of equipment components. Excessive temperature may cause combustion, explosion and even equipment damage or quality accidents. Shanghai Nanyue Electric's wireless temperature measurement can monitor the frequent occurrence of electrical equipment such as switch cabinets in real time, and can effectively control the occurrence of electrical accidents in a timely and effective manner.
①, high-voltage switchgear moving contacts, static contacts, cable contacts and other temperature online monitoring;
②, low-voltage switchgear contacts, cable joints and other temperature online monitoring;
③. Capacitors; online temperature monitoring of circuit breakers, isolating switches, etc.;
④. On-line monitoring of the temperature of the cable joints of the motor outlet box;
⑤, on-line monitoring of the temperature of the cable tunnel cable surface, cable joints, cable interlayer, etc.;
⑥. On-line temperature monitoring of electrical nodes in substations or outdoor important circuits;
⑦, on-line monitoring of the electrical node temperature in the transformer;
⑧, online monitoring of the electrical node temperature in the rectifier cabinet;



inner diameter Input Current Turns ratio Workload Voltage Output Power
50*14mm 2A 4000T 3.3K 1.7V 0.8mW
50*14mm 5A 4000T 3.3K 3.2V 3mW

Electrical Nodes Wireless Temperature Sensors Controller 433MHz 0Electrical Nodes Wireless Temperature Sensors Controller 433MHz 1Electrical Nodes Wireless Temperature Sensors Controller 433MHz 2
