10A Sensor Mumetal Permalloy Split Core Epoxy Resin 1j85

10A Sensor Mumetal Permalloy Split Core Epoxy Resin 1j85
10A Sensor Mumetal Permalloy Split Core Epoxy Resin 1j85

Large Image :  10A Sensor Mumetal Permalloy Split Core Epoxy Resin 1j85

Product Details:
Place of Origin: China
Brand Name: HEMEI
Model Number: 66*18*2MM
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: USD0.8/PCS
Packaging Details: Standard Carton
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000PCS/Month

10A Sensor Mumetal Permalloy Split Core Epoxy Resin 1j85

Description
Material: Permalloy Type: Current Transformer
Magnetic Circuit Structure: Single Stage Type Phase: Single
Insulating Medium: Epoxy Resin Core: Permalloy
Primary Input: 10A Output Power: 6.1MW Min
Winding Form: Single Layer & Tightly Wound Type
High Light:

1j85 Mumetal Permalloy

,

10A Sensor Mumetal Permalloy

,

Epoxy Resin Permalloy Split Core

Mumetal Permalloy 1j85 Split Cores for Sensor

current transformer are general applied in electronic energy meter, power transducer, precision power

meter and other power and energy monitoring devices ,over current protection circuit of motor and other

electrical appliances .



size Input Current Turns ratio Workload Voltage Output Power
66*18*2mm 10A 3500T 3.3K 6.2V 11mW
68*10*2mm 10A 4100T 3.3K 4.5V 6mW
73*10*2mm 10A 4100T 3.3K 4.5V 6mW
