Single Stage Permalloy Punch Core Toroidal Current Transformer Coil

Certification
China Hefei Hemei Electronics Technology Co., Ltd certification
I'm Online Chat Now

Single Stage Permalloy Punch Core Toroidal Current Transformer Coil

Single Stage Permalloy Punch Core Toroidal Current Transformer Coil
Single Stage Permalloy Punch Core Toroidal Current Transformer Coil

Large Image :  Single Stage Permalloy Punch Core Toroidal Current Transformer Coil

Product Details:
Place of Origin: China
Brand Name: HEMEI
Certification: CE/UL
Model Number: 66*18*2MM
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: negotiable
Packaging Details: Standard Carton
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000PCS/Month

Single Stage Permalloy Punch Core Toroidal Current Transformer Coil

Description
Material: Permalloy Usage: Current Transformer
Magnetic Circuit Structure: Single Stage Type Core: Toroidal
High Light:

Single Stage permalloy punch core

,

Toroidal permalloy punch core

,

Toroidal current transformer coil

66*18*2MM Permalloy Punch Core For Current Transformer



Permalloy refers to an iron-nickel alloy with a wide range of nickel content, ranging from 35% to 90%. The biggest feature of Permalloy is its high magnetic permeability in weak magnetic fields. Their saturation magnetic induction intensity is generally between 0.6-1.0T.



size Input Current Turns ratio Workload Voltage Output Power
66*18*2mm 10A 3500T 3.3K 6.2V 11mW
68*10*2mm 10A 4100T 3.3K 4.5V 6mW
73*10*2mm 10A 4100T 3.3K 4.5V 6mW

Single Stage Permalloy Punch Core Toroidal Current Transformer Coil 0
