Product Details:
|
| Warranty: | 1 Year | Input Voltage: | Power Supply Voltage |
|---|---|---|---|
| Starting Mode: | Self-excited Switching Power Supply | Modulation System: | Pfm/PWM |
| Output Power: | Less Than 1W | Certification: | Voltage RegulaRoHS, ISOting Mode |
| High Light: | 1W Switching Mode Power Supply,Pfm Switching Mode Power Supply,PWM current transformer switch |
||
CT Switching Power Supply
The split core current transformer is installed online. The input cable passes through the middle hole. After passing the transformer, the secondary output current signal is converted into the required voltage signal by the sampling resistor. Measuring type transformer, the transformer can be directly fixed on the cable with a diameter of 10mm ~ 21mm. This product is installed online without power interruption. All places operated by everyone are insulators, which is convenient, simple and fast to install.
Application:
Suitable for motor protection ,relay protection,small current grounding system
Suitable for electrical fire monitoring systems
Flexible output method
Through structure ,epoxy resin casting,good stability
High permeability permalloy or nanocrystalline ,with good linearity and high sensitivity
Excellent balance characteristics and extremely strong immunity to electromagnetic fields.split-core current transformers. The CT can be mounted to existing panels, such as control centers or load centers, to measure or monitor wattage. These CTs can be mounted without removing existing cables for easier installation.
Parameter:
| Item | Model | Input current(A) | Output voltage(V) | Output power(W/mW) |
| HM010M | HM010M-3.3 | 2-10 | 3.3 | 10mW |
| HM050M | HM050M-5.0 | 5-10 | 5 | 50mW |
| HM010M | HM010M-3.3 | 5-10 | 3.3 | 100mW |
| HM500M | HM500M-5.0 | 5-10 | 5 | 500mW |
| HM001W | HM001W-5.0 | 10-15 | 5 | 1W |
| HM003W | HM003W-5.0 | 15-20 | 5 | 3W |
| HM005W | HM005W-12 | 20-30 | 12 | 5W |
| HM010W | HM010W-12 | 30-40 | 12 | 10W |
